Metal Coil Cutting Machine

The Metal Coil Cutting Machine from Shijiazhuang Faith Machinery Co.,Ltd handles a variety of metal strips—steel, aluminum, copper—cutting them into specified lengths for diverse industries including electronics, construction, and automotive.

Equipment Layout

1. Universal Decoiler

• Adjustable mandrels fit coil IDs from 508 mm to 610 mm, with polymer sleeves to protect softer metals.

2. Leveling & Strip Guidance

• Pinch rolls and entry levelers flatten strip and correct surface imperfections before cutting.

3. Flying Shear Unit

• Interchangeable blade sets (HSS for steel, carbide for aluminum) shear strip to length without line stoppage.

• Servo-controlled blade gap and feeding speed ensure burr-free ends.

4. Discharge & Collection

• Cut lengths are conveyed to stacking areas or packaging stations.

• Scrap conveyors collect off-cuts, directing them to recycling bins.

Key Capabilities

• Length Range: 200 mm to 6,000 mm with ±1 mm accuracy.

• Thickness Range: From 0.2 mm to 8 mm for various metals.

• Width Capacity: Up to 1,800 mm, with quick-change guides for different widths.

Control and Diagnostics

An operator-friendly HMI stores a library of cutting recipes for different materials. Blade force sensors detect abnormal loads, preventing damage. Production reports export cut counts and material usage to MES for traceability.

Maintenance and Lifecycle

Tool-free blade holder design reduces changeover time to under 20 minutes. A centralized lubrication system services shear bearings and guide rolls at scheduled intervals. A stocked parts program ensures rapid availability of blades, sleeves, and drive belts.
