1.FUNCTION
This machine is designed and built on-line or off-line to test ERW pipes with pressurized water in continuous and automatic manner.
2. APPLICATION
Testing for:
● ERW Carbon Steel Pipes
● Water and gas pipes
● API oil pipes
● Galvanized pipes
3.Testing pressure
5~130Mpa(725~18,850psi)，according to the customer's requirements.
4.Process flow
Loading pipes➔Flushing ➔Conveyor➔Pipe end aligning ➔Clamping ➔Lower pressure water filling➔ Pressurized water filling➔Pressure holding➔Clamp releasing➔Unloading pipes
4.MODELS
Model | Round Tube | |
O.D(mm) | Thickness (mm) | |
HT32 | Φ12~Φ32 | 0.5~2.5 |
HT60 | Φ12~Φ63 | 0.6~3 |
HT76 | Φ25~Φ76 | 1~4 |
HT89 | Φ32~Φ89 | 1.5~4.5 |
HT127 | Φ48~Φ127 | 1.5~5 |
HT165 | Φ60~Φ165 | 2~6 |
HT254 | Φ114~Φ254 | 3~8 |
HT273 | Φ114~Φ273 | 4~10 |
HT325 | Φ165~Φ325 | 4~12 |
HT426 | Φ165~Φ426 | 6~14 |
HT508 | Φ165~Φ508 | 6~16 |
HT630 | Φ325~Φ630 | 6~20 |
Note: the above models are for reference, can be customized according to requirements.
5. FEATURESE
● Our technology as the same as that of German Mannesmann Company and Japanese YAMAMOTO SUIATU KOGYOSHO CO., LTD.
● Stress of uniformly, and simple installation.
● Radial gap seal is provided with good sealing and long service life.
● The water pressure is controlled by the high pressure pump, with high reliable pressure holding, and rapidly response.
● The oil or water pressure is detested by the pressure sensor automatically, which has high detection accuracy and sensitive response.
● Pressure test value LCD digital display, intuitive and reliable.
● The pressure holding time can be set arbitrarily, and it is controlled by the knob at the operation panel , which is convenient and simple.
● Automatic pressure detection: automatically displays on screen, and the pressure is displayed independently.
● PLC control the pressure testing process, which can automatically record the results of each test.
● The traverse of tail stock is controlled by hydraulic, high working efficiency, short test period.
● Operation mode: automatic and manual to push button.
6. OUR SERVICES
● Provide integral solutions.
● Provide customized solutions.
● Provide equipment modification and upgrade services.
● Provide turnkey projects.
● Provide free technical consultation.
● Provide performance testing before shipment.
● Provide remote fast fault diagnosis and resolution.
● Provide fast supply spare parts.
 |  |  |
 |  |  |
 |  |  |
