Linear Cage Forming Profile Mills

Share to:

1) High strength: High designed strength, high strength material is adopted to process heat treatment, which will enhance material strength and eliminate internal stress.

2) High precision: CNC machine tool precision machining to ensure machining accuracy and assembly accuracy, while reducing equipment loss.

3) High automation: Equipment main movement driven by hydraulic motor and controlled by PLC, which could save labor and labor intensity.

Availability:



Inquire

APPLICATION
MODELS
ADVANTAGE
VIDEO
PARTNER

1. TUBES APPLICATION

● Structural tubes

● Car tubes

● Tower base tubes

● Greenhouse tubes

● Door and window tubes

● Furniture tubes

● Photovoltaic support tubes

● Guardrail tubes

● Mechanical tubes

2. TUBES METERIAL

● Cold and hot rolled carbon steel

● Low and high resistance carbon steel

● Galvanized, galvanized aluminium, aluminized steel

3. TUBES STANDARD

EN, ASTM, JIS, DIN, GB

1.TUBE MILL MODELS

Model	Square TubeO.D(mm)	Rectangle Tube O.D(mm)	Thickness (mm)
CFS60	20×20~60×60	25×20~80×40	0.8~3
CFS100	30×30~100×100	35×30~120×80	1~4
CFS150	50×50~150×150	60×50~200×100	2~6
CFS200	80×80~200×200	90×80~250×150	3~8
CFS250	100×100~250×250	110×100~300×200	4~10
CFS300	150×150~300×300	160×150~350×250	5~12
CFS400	200×200~400×400	210×200~450×350	6~16
CFS500	250×250~500×500	260×250~550×450	8~20

Note: the above models are for reference, can be customized according to requirements.

2. TECHNICAL PROCESS

Coil loading➔Uncoiling➔Coil Peeling➔Strip Flattening➔Strip End Joining➔Strip Accumulating➔Forming➔H.F. Welding ➔External Scarfing➔Zinc Spraying and Dust Collecting➔Welding Seam Ironing➔Water Cooling➔Eddy Current Testing (ET) ➔Sizing➔Rough Straightening➔Marking➔Cutting Off➔Conveying➔Packing➔Weighing➔Storing

Note: the above technical process is for reference, can be customized according to requirements.
